Model Number Technical Specifications
MicroBlade SDN Switch Module MBM-GEM-001

MicroBlade SDN Switch Module :
MBM-GEM-001

Call for Pricing for MBM-GEM-001

General Specification:
• Intel® FM5224 GbE Low Latency Switch
• 1Gbps RJ45, 2x 40Gbps QSFP or 8x 10Gbps SFP+ uplinks
• 56x 2.5Gbps or 1Gbps downlinks
• 1 Console port
• 1 USB port

Switching Capacity: 442Gbps

Physical Layer Features:
• Jumbo frames up to 9KB
• 40 gigabit optical/copper
• 10 gigabit optical Ethernet SFP+/copper
• 1 gigabit RJ45 Ethernet
• 1 gigabit optical Ethernet copper

Layer 2 Features:
• 4K VLANS
• Spanning Tree (802.1D)
• Rapid Spanning Tree (802.1w)
• Multiple Spanning Trees (802.1s)
• IEEE 802.lQ VLANs/ port-based VLANs
• IEEE 802.3ac VLAN tagging
• IEEE 802.1AX LAG
• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

Advanced Layer 2 Features:
• Storm control
• Flow control
• Port mirroring
• Static MAC filtering
• UDLD
• Uplink Failure Detection (UFD)

Data Center Features:
• L2 Data Center Bridging
• CEE v1.01 DCB for PFV/ETS

SDN: Open Flow 1.x

Security Features:
• Switch access password protection
• RADIUS and TACACS+ Authentication
• Access Control Lists (to 4K)
• SSH, SSL Encryption

System Management:
• XML-RPC
• Industry Standard CLI
• Command completion
• Content-sensitive "Help"
• SNMP v1/v2/v3
• SSH
• TFTP Client
• Syslog
• DHCP (Client)
• Web-based management interface - (future) - HTTP/HTTPS
• NTP

Multicast: IGMP Snooping
Weight: 3.2lbs/1.5kg
Dimension: 267mm x 159mm x 36mm (10.5" x 6.25" x 1.4")

Supermicro SDN Switch Module MBM-XEM-001

MicroBlade SDN Switch Module :
MBM-XEM-001

Call for Pricing for MBM-XEM-001



General Specification:
• Intel® FM6348 10GbE Low Latency Switch
• 4x 40Gbps QSFP uplinks
• 56x 10Gbps or 1Gbps downlinks
• 1 Console port
• 1 USB port

Switching Capacity: 960Gbps

Physical Layer Features:
• Jumbo frames up to 9KB
• 40 gigabit optical/copper
• 1 gigabit optical Ethernet copper

Layer 2 Features:
• 4K VLANS
• Spanning Tree (802.1D)
• Rapid Spanning Tree (802.1w)
• Multiple Spanning Trees (802.1s)
• IEEE 802.lQ VLANs/ port-based VLANs
• IEEE 802.3ac VLAN tagging
• IEEE 802.1AX LAG
• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

Advanced Layer 2 Features:
• Storm control
• Flow control
• Port mirroring
• Static MAC filtering
• UDLD
• Uplink Failure Detection (UFD)

Data Center Features:
• L2 Data Center Bridging
• CEE v1.01 DCB for PFV/ETS

SDN: Open Flow 1.x

Security Features:
• Switch access password protection
• RADIUS and TACACS+ Authentication
• Access Control Lists (to 4K)
• SSH, SSL Encryption

System Management:
• XML-RPC
• Industry Standard CLI
• Command completion
• Content-sensitive "Help"
• SNMP v1/v2/v3
• SSH
• TFTP Client
• Syslog
• DHCP (Client)
• Web-based management interface - (future) - HTTP/HTTPS
• NTP

Multicast: IGMP Snooping
Weight: 3.2lbs/1.5kg
Dimension: 267mm x 159mm x 36mm (10.5" x 6.25" x 1.4")

Supermicro MicroBlade MBM-XEM-004 Module

MicroBlade Switch Module :
MBM-XEM-004

Call for Pricing for MBM-XEM-004

General Specification:
• Broadcom BCM56846 10GbE Low Latency Switch
• 2x 40Gbps QSFP or 4x 10Gbps SFP+ uplinks
• 56x 10Gbps or 1Gbps downlinks
• 1 Console port
• 1 USB port

Switching Capacity: 1280Gbps

Physical Layer Features:
• Jumbo frames up to 9KB
• 40 gigabit optical/copper
• 10 gigabit optical Ethernet SFP+/copper

Layer 2 Features:
• 4K VLANS
• Spanning Tree (802.1D)
• Rapid Spanning Tree (802.1w)
• Multiple Spanning Trees (802.1s)
• IEEE 802.lQ VLANs/ port-based VLANs
• IEEE 802.3ad with LACF
• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)

Advanced Layer 2 Features:
• Storm control
• Flow control
• Port mirroring

Other Features:
• IP Source Guard
• VRRP

Security Features:
• Switch access password protection
• RADIUS and TACACS+ Authentication
• Access Control Lists (to 4K)
• SSH, SSL Encryption

System Management:
• XML-RPC
• Industry Standard CLI
• SNMP v1/v2/v3
• SSH
• Syslog
• DHCP (Client)
• Web-based management interface - (future)
• NTP
• RMON

Multicast: IGMP Snooping
Weight: 3.2lbs/1.5kg
Dimension: 267mm x 159mm x 36mm (10.5" x 6.25" x 1.4")
