Supermicro 1U Rackmount SuperServer SYS-5019S-L

Call for price.

SKU:SYS-5019S-L

Quick Overview:

Key Features:
• Mainstream, Entry Appliance
• Low Power, Cost effective
• Single socket H4 (LGA 1151) supports Intel® Xeon® processor E3-1200
v5, Intel® 6th Gen. Core™ i3 series
• Intel® C232 chipset
• 1x 3.5" Fixed drive bay or 2x 2.5" drive option
• Up to 64GB Unbuffered ECC UDIMM DDR4 2133MHz; 4x DIMM slots
• 1x PCI-E 3.0 x8 AOC slot
• 2x GbE ports with Intel® i210-AT 1x shared IPMI port
• I/O ports: 1x VGA, 1x COM, 2x USB 2.0, USB 3.0
• 200W Multi-output power supply

Description

Details

SuperServer SYS-5019S-L 1U Rackmount

Supermicro SYS-5019S-L 1U Rackmount with 200W Multi-output power supply, 1x 3.5" or 2x 2.5" internal drive bays (fixed), using Supermicro Super X11SSL-F Motherboard and
CSE-510-203B Rackmount Chassis

Product SKU
SYS-5019S-L	• SuperServer 5019S-L (Black)

Motherboard
	Super X11SSL-F

Processor/Cache
CPU	• Single Socket H4 (LGA 1151) supports: • Intel® Xeon® processor E3-1200 v5, Intel® 6th Gen Core™ i3 • CPU TDP up to 45W, 80W option fan

System Memory
Memory Capacity	• 4x 288-pin DDR4 DIMM slots • Up to 64GB DDR4 ECC UDIMM
Memory Type	• 2133/1866/1600MHz ECC DDR4 SDRAM 72-bit, 288-pin (UDIMM) gold-plated DIMMs
DIMM Sizes	• 16GB, 8GB, 4GB
Memory Voltage	• 1.2 V
Error Detection	• Corrects single-bit errors • Detects double-bit errors (using ECC memory)

On-Board Devices
Chipset	• Intel® C232 chipset
SATA/SAS	• SATA3 (6Gbps) via C232 controller • RAID 0, 1, 5, 10 support
IPMI	• Support for Intelligent Platform Management Interface v.2.0 • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support • ASPEED AST2400 BMC
Network Controllers	• Dual Intel® I210-AT Gigabit Ethernet LAN ports • Supports 10BASE-T, 100BASE-TX, and 1000BASE-T, RJ45 output
Video	• ASPEED AST2400 BMC

Input/Output
SATA	• 2x SATA3 (6Gbps) ports
LAN	• 2x RJ45 Gigabit Ethernet LAN ports • 1x RJ45 Shared IPMI LAN port
USB	• USB 3.0 • 2x USB 2.0 ports
Video	• 1x VGA port
Serial Port / Header	• 1x COM ports (1 rear)
SuperDOM	• 2x SuperDOM (Disk on Module) ports with built-in power

Chassis
Form Factor	• 1U Rackmount
Model	• CSE-510-203B

Dimension and Weight
Height	• 1.7" (43mm)
Width	• 17.2" (437mm)
Depth	• 11.3" (287mm)
Weight	• 12.55 lbs (5.69 kg)
Available Color	• Black

Front Panel
Buttons	• Power On/Off button
LEDs	• Power LED • Hard drive activity LED • 2x Network activity LEDs • System Overheat LED • Information LED (temp., status)

Expansion Slots
PCI-E	• 1x PCI-E 3.0 x8 AOC slot

Drive Bays
Optional	• 1x 3.5" or 2x 2.5" internal drive bays (fixed)

System Cooling
Fans	• 2x 40x28mm 4-pin PWM Cooling Fans • 1x FAN-0147L4 option for 80W CPU

Power Supply
	200W Low Noise AC-DC power supply with PFC
AC Voltage	• 100 - 240V, 50-60Hz, 2.6 Amp Max
+5V	• 8.0 Amp (max.)
+5V standby	• 2.0 Amp (max.)
+12V	• 16 Amp (max.)
-12V	• 0.5 Amp (max.)
+3.3V	• 8.0 Amp (max.)
Certification	• Gold Certified

System Bios
Bios Type	• 8MB SPI Flash EEPROM with AMI BIOS
Bios Features	• DMI 2.3 • PCI 2.3 • ACPI 1.0 / 2.0 • USB Keyboard support • SMBIOS 2.3

Operating Environment / Compliance
RoHS	• RoHS Compliant
Environmental Spec.	• Operating Temperature: 10°C to 40°C (50°F to 104°F) • Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) • Operating Relative Humidity: 8% to 90% (non-condensing) • Non-operating Relative Humidity: 5% to 95% (non-condensing)
