Details
Intel® Core™ i3-6100U Processor | 6th Gen | 2.30GHz | Skylake
|
Essentials
| |
|---|---|
| • Product Collection | • 6th Generation Intel® Core™ i3 Processors |
| • Code Name | • Products formerly Skylake |
| • Vertical Segment | • Mobile |
| • Processor Number | • i3-6100U |
| • Lithography | • 14 nm |
| Performance
|
|
|---|---|
| # of Cores | • 2 |
| # of Threads | • 4 |
| Processor Base Frequency | • 2.30 GHz |
| Cache | • 3 MB SmartCache |
| Bus Speed | • 4 GT/s OPI |
| TDP | • 15 W |
| Configurable TDP-down Frequency |
• 800 MHz |
| Configurable TDP-down | • 7.5 W |
| Embedded Options Available | • Yes |
|
Memory Specification
| |
|---|---|
| Max Memory Size (dependent on memory type) |
• 32 GB |
| Memory Type | • DDR4-2133, LPDDR3-1866, DDR3L-1600 |
| Max # of Memory Channels | • 2 |
| Max Memory Bandwidth | • 34.1 GB/s |
| ECC Memory Supported | • No |
|
Processor Graphics
| |
|---|---|
| Processor Graphics | • Intel® HD Graphics 520 |
| Graphic Base Frequency | • 300 MHz |
| Graphics Max Dynamic Frequency |
• 1.00 GHz |
| Graphics Video Max Memory | • 32 GB |
| Graphics Output | • eDP/DP/HDMI/DVI |
| 4K Support | • Yes, at 60Hz |
| Max Resolution (HDMI 1.4) | • 4096x2304@24Hz |
| Max Resolution (DP) | • 4096x2304@60Hz |
| Max Resolution (eDP - integrated Flat Panel) |
• 4096x2304@60Hz |
| DirectX Support | • 12 |
| OpenGL Support | • 4.5 |
| Intel Quick Sync Video | • Yes |
| Intel InTru 3D Technology | • Yes |
| Intel Clear Video HD Technology |
• Yes |
| Intel Clear Video Technology | • Yes |
| # of Display Supported | • 3 |
| Device ID | • 0x1916 |
|
Package Specifications
| Socket Supported | • FCBGA1356 | Max CPU Configuration |
• 1 |
|---|---|
| TJUNCTION | • 100°C |
|
Expansion Options
| |
|---|---|
| PCI Express Revision | • 3.0 |
| PCI Express Configuration | • 1x4, 2x2, 1x2+2x1 and 4x1 |
| Max # of PCI Express Lanes |
• 12 |
|
Advanced Technologies
| |
|---|---|
| Intel® Turbo Boost Technology | • No |
| Intel® vPro™ Platform Eligibility |
• No |
| Intel® Hyper-Threading Technology |
• Yes |
| Intel® Virtualization Technology (VT-x) |
• Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) |
• Yes |
| Intel® VT-x with Extended Page Tables (EPT) |
• Yes |
| Intel® TSX-NI | • No |
| Intel® 64 | • Yes |
| Instruction Set | • 64-bit
|
| Instruction Set Extension | • Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
|
| Idle States | • Yes |
| Enhanced Intel SpeedStep® Technology |
• Yes |
| Thermal Monitoring Technologies |
• Yes |
| Intel® Flex Memory Access | • Yes |
| Intel® Identity Protection Technology |
• Yes |
| Intel® Stable Image Platform Program (SIPP) |
• No |
| Intel® Smart Response Technology |
• Yes |
| Intel® My WiFi Technology | • Yes |
|
Security & Reliability
| |
|---|---|
| Intel® AES New Instructions |
• Yes |
| Secure Key | • Yes |
| Intel® Software Guard Extensions (Intel® SGX) |
•Yes with Intel® ME |
| Intel® Memory Protection Extensions (Intel® MPX) |
• Yes |
| Intel® Trusted Execution Technology |
• No |
| Execute Disable Bit | • Yes |
| Intel® OS Guard |
• Yes |
