Intel® Xeon® x3-C3445 Processor | 1.40GHz | SoFIA LTE
Details
Intel® Xeon® x3-C3445
Processor | 1.40GHz | SoFIA LTE
|
Essentials
| |
|---|---|
| Product Collection | • Intel® Atom™ Processor X Series |
| Code Name | • Code Name Products formerly SoFIA LTE |
| Vertical Segment | • Mobile |
| Processor Number | • x3-C3445 |
| Lithography | • 28 nm |
| Performance
|
|
|---|---|
| # of Cores | • 4 |
| # of Threads | • 4 |
| Processor Base Frequency | • 1.20 GHz |
| Burst Frequency | • 1.40 GHz |
| Cache | • 1 MB |
| Scenario Design Power (SDP) |
• 2 W |
| Embedded Options Available |
• No |
|
Memory Specification
| |
|---|---|
| Max Memory Size (dependent on memory type) |
• 2 GB |
| Memory Type | • 1x32 LPDDR2/3 1066 |
| Max # of Memory Channels | • 1 |
| Max Memory Bandwidth | • 4.2 GB/s |
|
Processor Graphics
| |
|---|---|
| Graphics Base Frequency | • 456 MHz |
| Graphics Output | • MIPI DSI |
| Max Resolution (eDP - Integrated Flat Panel) |
• 1280x800 |
| DirectX* Support | • 9.3 |
| OpenGL* Support | • ES 3.0 |
| # of Displays Supported | • 1 |
|
Package Specifications
| Operating Temperature Range | • -25°C to 85°C |
|---|---|
| Low Halogen Options Available | • 12mm x 12mm |
|
Advanced Technologies
| |
|---|---|
| Secure Boot | • Yes |
| Instruction Set | • 64-bit |
