Details
|
Essentials
| |
|---|---|
| • Product Collection | • 8th Generation Intel® Core™ i7 Processors |
| • Code Name | • Products formerly Kaby Lake G |
| • Vertical Segment | • Mobile |
| • Processor Number | • i7-8705G |
| • Lithography | • 14 nm |
| Performance
|
|
|---|---|
| # of Cores | • 4 |
| # of Threads | • 8 |
| Processor Base Frequency | • 3.10 GHz |
| Max Turbo Frequency | • 4.10 GHz |
| Cache | • 8 MB |
| Bus Speed | • 8 GT/s DMI |
| Embedded Options Available | • No |
|
Memory Specification
| |
|---|---|
| Max Memory Size (dependent on memory type) |
• 64 GB |
| Memory Type | • DDR4-2400 |
| Max # of Memory Channels | • 2 |
| Max Memory Bandwidth | • 37.5 GB/s |
| ECC Memory Supported | • No |
|
Discrete Graphics
| |
|---|---|
| Graphics Name‡ | • Radeon™ RX Vega M GL Graphics |
| Graphics Max Dynamic Frequency | • 1011 MHz |
| Graphics Base Frequency | • 931 MHz |
| Compute Units | • 20 |
| Graphics Memory Bandwidth | • 179.2 GB/s |
| Graphics Memory Interface | • 1024 bit |
| Graphics Output | • eDP 1.4, DP 1.4 w/ HDR, HDMI 2.0b, DVI |
| 4K Support | • Yes, at 60Hz |
| Max Resolution (HDMI) | • 4096 x 2160@60Hz |
| Max Resolution (DP) | • 4096 x 2160@60Hz |
| Max Resolution (eDP - Integrated Flat Panel) |
• 4096 x 2160@60Hz |
| DirectX* Support | • 12 |
| Vulkan* Support | • Yes |
| OpenGL* Support | • 4.5 |
| H.264 Hardware Encode/Decode | • Yes |
| H.265 (HEVC) Hardware Encode/Decode |
• Yes, 10-bit |
| # of Displays Supported | • 6 |
|
Processor Graphics
| |
|---|---|
| Processor Graphics | • Intel® HD Graphics 630 |
| Graphic Base Frequency | • 350 MHz |
| Graphics Max Dynamic Frequency |
• 1.10 GHz |
| Graphics Video Max Memory | • 64 GB |
| Graphics Output | • eDP 1.4, DP 1.2, HDMI 1.4, DVI |
| 4K Support | • Yes, at 60Hz |
| Max Resolution (HDMI 1.4) | • 4096 x 2160 @30Hz |
| Max Resolution (DP) | • 4096 x 2160 @60Hz |
| Max Resolution (eDP - integrated Flat Panel) |
• 4096 x 2160 @60Hz |
| DirectX Support | • 12 |
| OpenGL Support | • 4.4 |
| Intel Quick Sync Video | • Yes |
| Intel InTru 3D Technology | • Yes |
| Intel Clear Video HD Technology |
• Yes |
| Intel Clear Video Technology | • Yes |
| # of Display Supported | • 3 |
|
Package Specifications
| Socket Supported | • BGA2270 | Max CPU Configuration |
• 1 |
|---|---|
| TJUNCTION | • 100°C |
|
Expansion Options
| |
|---|---|
| PCI Express Revision | • 3.0 |
| PCI Express Configuration | • Up to 1x8, 2x4 |
| Max # of PCI Express Lanes |
• 8 |
|
Advanced Technologies
| |
|---|---|
| Intel® Speed Shift Technology | • Yes |
| Intel® Turbo Boost Technology | • 2.0 |
| Intel® vPro™ Platform Eligibility |
• No |
| Intel® Hyper-Threading Technology |
• Yes |
| Intel® Virtualization Technology (VT-x) |
• Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) |
• Yes |
| Intel® VT-x with Extended Page Tables (EPT) |
• Yes |
| Intel® TSX-NI | • No |
| Intel® 64 | • Yes |
| Instruction Set | • 64-bit
|
| Instruction Set Extension | • Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
|
| Intel® My WiFi Technology | • Yes
|
| Idle States | • Yes
|
| Enhanced Intel SpeedStep® Technology |
• Yes
|
| Thermal Monitoring Technologies |
• Yes |
| Intel® Flex Memory Access | • Yes |
| Intel® Identity Protection Technology |
• Yes |
| Intel® Stable Image Platform Program (SIPP) |
• No |
| Intel® Smart Response Technology |
• Yes |
|
Security & Reliability
| |
|---|---|
| Intel® AES New Instructions |
• Yes |
| Secure Key | • Yes |
| Intel® Software Guard Extensions (Intel® SGX) |
• Yes with Intel® ME |
| Intel® Memory Protection Extensions (Intel® MPX) |
• Yes |
| Intel® OS Guard | • Yes |
| Intel® Trusted Execution Technology |
• No |
| Execute Disable Bit |
• Yes |
