Supermicro SuperServer SYS-F618R2-FT
|
Product SKU
| |
|---|---|
| SYS-F618R2-FT | • SuperServer F618R2-FT (Black) |
|
Motherboard
| |
|---|---|
| • Super X10DRFF | |
| Processor/Cache
|
|
|---|---|
| CPU | •
Processor/Cache
CPU Intel® Xeon® processor E5-2600 v4†/ v3 family (up to 145W TDP)
• Dual Socket R3 (LGA 2011) |
| Cores/Cache | • Up to 22 Cores† / Up to 55MB† Cache |
| System Bus | • QPI up to 9.6 GT/s |
| † BIOS version 2.0 or above is required | |
| Note | Please contact Will Jaya Technical Support for additional information about frequency optimized CPUs and specialized system optimization. |
|
System Memory
| |
|---|---|
| Memory Capacity | • 8x 288-pin DDR4 DIMM slots • Up to 1TB† ECC 3DS LRDIMM, 512GB ECC RDIMM |
| Memory Type |
• 2400†/2133/1866/1600MHz ECC DDR4 SDRAM 72-bit |
| DIMM Sizes | • RDIMM: 64GB, 32GB, 16GB, 8GB, 4GB • LRDIMM: 64GB, 32GB • 3DS LRDIMM: 128GB |
| Memory Voltage | • 1.2 V |
| Error Detection | • Corrects single-bit errors |
|
On-Board Devices
| Chipset | • Intel® C612 chipset |
|---|---|
| SATA | • SATA3 (6Gbps) with RAID 0, 1 |
| IPMI | • Support for Intelligent Platform • IPMI 2.0 with virtual media over LAN and KVM-over-LAN support • ASPEED AST2400 BMC |
| Network Controllers | • Dual Intel® i210 Single Port Gigabit Ethernet |
| Graphics |
• ASPEED AST2400 BMC |
|
Input/Output (per node)
| SATA | • 2x SATA3 (6Gbps) ports | LAN | • 2x RJ45 Gigabit Ethernet LAN ports • 1x RJ45 Dedicated IPMI LAN port |
USB | • 2x USB 3.0 ports |
|---|---|
| VGA |
• 1x VGA port |
|
Chassis
| |
|---|---|
| Form Factor | • 4u Rackmount |
| Model | • CSE-F418IL-R1K62BP |
|
Dimension and Weight
| |
|---|---|
| Width | • 17.63" (448mm) |
| Height | • 6.96" (177mm) |
| Depth | • 29" (737mm) |
| Gross Weight | • 200 lbs (90.71 kg) |
| Available Colors | • Black |
|
Front Panel
| |
|---|---|
| Buttons |
• Power On/Off button |
| LEDs | •
Power status LED • 2x Network activity LEDs |
|
Expansion Slots (per node)
| |
|---|---|
| PCI-Express |
• 1x PCI-E 3.0 x16 Low-profile via riser card |
|
Drive Bays (per node)
| |
|---|---|
| Hot-swap |
• 2x 2.5" Hot-swap SATA HDD trays |
|
System Cooling
| |
|---|---|
| Fans |
• 8x 8cm 9.5K RPM Rear Fans |
|
Power Supply
| |
|---|---|
| 1620W high-efficiency redundant power supply w/ PMBus | |
| AC Input | • 1000W Output @ 100-120V, 12-10A, 50-60Hz • 1200W Output @ 120-140V, 12-10A, 50-60Hz • 1620W Output @ 180-240V, 10.5-8A, 50-60Hz |
| DC Output |
• 1000W: +12V/84A; +5Vsb/4A • 1200W: +12V/100A; +5Vsb/4A • 1620W: +12V/150A; +5Vsb/4A |
| Certification | • Platinum Certified |
|
System BIOS
| |
|---|---|
| BIOS Type |
• 128Mb SPI Flash EEPROM with AMI BIOS |
| BIOS Features | • Plug and Play (PnP) • APM 1.2 • PCI 2.3 • USB Keyboard support • SMBIOS 2.7.1 • UEFI 2.3.1 |
|
Operating Environment
| |
|---|---|
| RoHS |
• RoHS Compliant |
| Environmental Spec. | • Operating Temperature:
10°C ~ 35°C (50°F ~ 95°F) • Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) • Operating Relative Humidity: 8% to 90% (non-condensing) • Non-operating Relative Humidity: 5% to 95% (non-condensing) |
