Details
Super X9DRT-HIBQF Motherboard and CSE-217HD-R1K28B chassis
Product SKU |
|
---|---|
SYS-2027TR-D70QRF | • SuperServer 2027TR-D70QRF (Black) |
Motherboard |
|
---|---|
Super X9DRT-HIBQF |
Processor/Cache |
|
---|---|
CPU | • Dual Socket R (LGA 2011) * Please contact your Supermicro sales representative for additional details |
Note | • † BIOS version 3.0 or above is required |
Cache | • Up to 30MB |
System Bus | • QPI up to 8 GT/s |
System Memory |
|
---|---|
Memory Capacity | • 8x 240-pin DDR3 DIMM slots • Up to 512GB DDR3 ECC LRDIMM • Up to 256GB DDR3 ECC Registered memory (RDIMM) |
Memory Type | • 1866/1600/1333/1066/800MHz ECC DDR3 SDRAM 72-bit, 240-pin gold-plated DIMMs |
DIMM Size | • 32GB, 16GB, 8GB, 4GB, 2GB, 1GB |
Memory Voltage | • 1.5 V, 1.35 V |
Error Detection | • Corrects single-bit errors • Detects double-bit errors (using ECC memory) |
On-Board Devices |
|
---|---|
Chipset | • Intel® C602 Chipset |
Infiniband | • Mellanox ConnectX-3 QDR Infiniband 40Gbps Controller |
SAS | • LSI 2008 SAS (6Gbps) |
SATA | • SATA 2.0 & 3.0 with RAID 0, 1, 5, 10 |
IPMI | • Support for Intelligent Platform Management Interface v.2.0 |
Network Controllers | • Intel® i350 Dual Port Gigabit Ethernet |
Graphics | • Matrox G200eW |
Input/Output (per Node) |
|
---|---|
SAS | • 12x SAS ports (6Gbps) • IT mode SAS option |
LAN | • 2x RJ45 Gigabit Ethernet LAN ports |
USB | • 3x USB 2.0 ports total
(2x rear + 1x Type A) |
VGA | • 1x VGA port |
Keyboard/Mouse | • PS/2 keyboard and mouse ports |
Serial Ports / Header | • 1x Fast UART 16550 port / 1 Header |
Infiniband | • 1 external QSFP Infiniband connector |
Chassis |
|
---|---|
Form Factor | • 2U Rackmount |
Model | • CSE-217HD-R1K28B |
Dimension and Weight |
|
---|---|
Height | • 3.47" (88mm) |
Width | • 17.25" (438mm) |
Depth | • 26.75" (679mm) |
Gross Weight | • 85 lbs (38.6kg) |
Available Color | • Black |
Front Panel |
|
---|---|
Buttons |
• Power On/Off button • System Reset button • UID button |
LED |
• Power status LED • HDD activity LED • 2x Network activity LEDs • Universal Information (UID) LED |
Expansion Slot (per node) |
|
---|---|
PCI-Express | • 3x PCI-E 3.0 (x8) slots via riser card (1x Low-profile, 2x Full-height, Full-length slots) |
Drive Bays (per node) |
|
---|---|
Hot-swap | • 12x Hot-swap 2.5" HDD trays |
System Cooling |
|
---|---|
Fans | • 4x 11K RPM cooling fans |
Power Suplly |
|
---|---|
1280W Redundant High-efficiency Digital Power Supplies w/ PMBus 1.2 | |
AC Input | • 1000W Output @ 100-140V, 8-12A, 50-60Hz • 1280W Output @ 180-240V, 6-8A, 50-60Hz |
DC Output | • 1000W: +12V/83A; +5Vsb/4A • 1280W: +12V/106.7A, +5Vsb/4A |
Certification | • Platinum Certified |
System Bios |
|
---|---|
BIOS Type | • 128Mb SPI Flash EEPROM with AMI BIOS |
BIOS Features | • Plug and Play (PnP) • APM 1.2 • PCI 2.2 • ACPI 1.0 / 2.0 • USB Keyboard support • SMBIOS 2.3 • UEFI |
Operating Environment / Compliance |
|
---|---|
RoHS | • RoHS Compliant |
Environmental Spec. | • Operating Temperature:
10°C to 35°C (50°F to 95°F)
|
